A182 F91 flange

Type:ASTM A182 F91 Flange
Standard:ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Dimension: 1/2in to 120in CL150 to CL3000
Feature:Stock regular sizes, Customized forge, design as per ASME VIII.
分类: 标签: ,

描述

Standard Specification For Alloy Steel ASTM A182 F91 Industrial Flanges

Specifications : ASTM A182 / ASME SA182

Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.

Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.

Size : 1/2″ to 36″

Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

ASTM A182 F91 hardness inspection

ASTM A182 F91 Alloy Steel Pipe Flanges

Forged and Plate Flanges

ProductsSize
ASTM A182 Alloy Steel F91 Slip-On FlangesASTM A182 Alloy Steel F91 Threaded FlangesSizes 1/8″ – 36″
Raised Face or Flat Face
ASTM A182 Alloy Steel F91 Weld Neck FlangesASTM A182 Alloy Steel F91 Socket Weld Flanges
ASTM A182 Alloy Steel F91 Blind FlangesASTM A182 Alloy Steel F91 Reducing Flanges
ASTM A182 Alloy Steel F91 Lap Joint FlangesASTM A182 Alloy Steel F91 Plate Flanges
ASTM A182 Alloy Steel F91 Orifice FlangesASTM A182 Alloy Steel F91 Forged Flanges
ASTM A182 Alloy Steel F91 Ring Type Joint FlangesASTM A182 Alloy Steel F91 Square Flanges

Alloy Steel F91 Flange Standards / Types And Pressure Class :

ASME/ANSI B 16.5Welding Neck Flange, Slip on Flange, Blind Flange, High Hub Blind Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Ring Type Joint Flange
PRESSURE CLASS150, 300, 400, 600, 900, 1500, 2500
ASME/ANSI B 16.47Welding Neck Flange, Blind Flange [Series A & B]
PRESSURE CLASS75, 150, 300, 400, 600, 900
ASME/ANSI B 16.36Welding Neck Flange, Slip on Flange, Threaded Flange
PRESSURE CLASS300, 400, 600, 900, 1500, 2500
BS 4504 SEC 3.1Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Lapped Pipe End Flange, Plate Flange, Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange
PRESSURE CLASSPN 2.5 TO PN 40
BS 4504[PART 1]Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange
PRESSURE CLASSPN 2.5 TO PN 400
BS 1560 BOSSWelding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange, Screwed Boss Flange, Lapped Flange
PRESSURE CLASS150, 300, 400, 600, 900, 1500, 2500
BS10Welding Neck Flange, Plate Slip-On Flange, Screwed Boss Flange, Slip-On Boss Flange, Blind Flange
TABLED, E, F, H
DIN FLANGESDIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673
PRESSURE CLASSPN 6 TO PN 100
Material GroupCommon NameTypeUNSForging Spec.Casting Spec. EquivalentDINDIN W. NoApplication
Low Alloy SteelMoly SteelC-1/2MoK12822A182-F1 cl2A217-WC115M031.5415Up to 470ºC* (875ºF)
Alloy Steel Chrome Moly1.1/4Cr-1/2MoK11572A182-F11 cl2A217-WC613CRM0441.7335Up to 593ºC (1100ºF)
2.1/4Cr-1MoK21590A182-F22 cl3A217-WC910CRM09101.7380Up to 593ºC (1100ºF), HP steam
5Cr-1/2MoK41545A182-F5/F5aA217-C512CRMO1951.7362High temp refinery service
9Cr-1MoK90941A182-F9A217-C12X 12 CrMo 9 11.7386High temp erosive refinery service
9Cr-1Mo-VA182-F91A217-C12AX 10 CrMoVNb 9 11.4903High pressure steam

clcik to preview more information: ASTM A182A182M-19 Standard Specification For Forged Or Rolled Alloy And Stainless Steel Pipe Flanges, Forged Fittings, And Valves And Parts For High-Temperature Service
